Description

Original Splined Hub 4110001903014 80513005 For G9190 G9220 Motor Grader

1 右平衡箱总成90 500 022 TANDEM DRIVE 4110001903001
2 行星减速器总成93 000 011 HUB REDUCTION 4110001903002
3 螺栓M16*1.5*85 50 011 031 SCREW 4110001903003
4 垫圈16 52 020 006 WASHER 4110001903004
5 主减速器总成82 513 600 FINAL DRIVE 4110001903005
6 通气塞80 513 007 AIR VENT COCK 4110001903006
7 螺栓M16*1.5*110 50 011 032 SCREW 4110001903007
8 左平衡箱总成90 500 021 TANDEM DRIVE 4110001903008
9 半轴80 513 003 SHAFT HALF 4110001903009
10 半轴80 513 004 SHAFT HALF 4110001903010
11 销16*70 51 240 010 PIN 4110001903011
12 制动器总成84 787 100 DRUM BRAKE 4110001903012
13 轮辋螺栓M22*1.5*84 80 513 006 WHEEL STUD 4110001903013
14 花键毂80 513 005 HUB 4110001903014
15 支承套85 513 041 SLEEVE 4110001903015
16 制动鼓80 513 002 BRAKE DRUM 4110001903016
17 轮辋螺母M22*1.5 51 017 001 NUT 4110001903017
18 圆螺母M75*2 80 513 012 NUT 4110001903018
19 垫圈8 52 020 002 WASHER 4110001903019
20 螺钉M8*12 50 120 022 SCREW 4110001903020
21 盖80 513 011 COVER 4110001903021
22 螺钉M10*30 50 140 003 SCREW 4110001903022
23 紧定螺钉M14*18 80 513 013 SCREW 4110001903023

1 左转向总成 STEERING KNUCKLE 28080002231
2 右旋球头 BALL JOINT 28080002541
3 锁紧螺母GB6173-M30×1.5-10 NUT 4013000319
4 前轮倾斜油缸 100*50*169-473 CYLINDER 4120004762
5 右转向总成 STEERING KNUCKLE 28080002321
6 前轮转向油缸右 63*45*340-577 STEERING CYLINDER 4120004763
7 前轮转向油缸左63*45*340-577 STEERING CYLINDER 4120004764
8 铰接轴 STEERING KNUCKLE 28080002181
9 铰接轴 STEERING KNUCKLE 28080002381
10 转向横拉杆 Tie rod 28080002131
11 螺栓GB5782-M16*50EpZn-8.8 BOLT 4011000510
12 垫圈LGB001-16 WASHER 4040000002
13 支座 SPACER 28080002421
14 垫圈GB97.1-24EpZn-300HV WASHER 4015000167
15 开口销GB91-4*45EpZn-Q235A SPLIT PIN 4016000057
16 螺母 NUT 28080002551
17 衬套 BUSHING 28080002451
18 关节轴承GB9163-GEG40ES-2RS SPHERICAL PLAIN BEARING 4021000289
19 挡圈GB893.1-68-65Mn RETAINING RING 4015000199
20 挡圈GB894.1-40-65Mn RETAINING RING 4015000132
21 复合轴承 BEARING 28080002141
22 锁止垫片 THRUST BEARING 28080002261
23 油杯JB7940.1-M10*1 LUBRICATING NIPPLE 4030000065
24 垫圈GB96.1-12EpZn-300HV WASHER 4015000186
25 铰接轴 STEERING KNUCKLE 28080002351
26 螺栓GB5783-M12*40EpZn-8.8 BOLT 4011000091
27 支座 SPACER 28080002441
28 螺栓GB5783-M12*30EpZn-8.8 BOLT 4011000089
29 支座 SPACER 28080002431
30 向心关节轴承GE35ES-2RS SPHERICAL PLAIN BEARING 4021000290
31 P挡圈GB893.1-55-65Mn RETAINING RING 4015000272
32 隔板 SPACER PLATE 28080002461
33 复合轴承 BEARING 28080002151
34 前桥架 AXLE FRAME 28080002031
35 连杆 LINK ROD 28080002221
36 销轴GB/T882 30*95 PIN 4016000317
37 开口销GB91-6.3*50EpZn-Q235A SPLIT PIN 4016000040
38 前桥标牌 Name plate 28080002851
39 铆钉GB827-3*5-BL2 RIVET 4019000012
