Lovol FL958G Wheel loader Condenser

No. Code Description Quantity
1 9F853-68A000002A0 TRANSITION JOINT 1
10 9F850-62A000001A0 LOCK CABLE TIESZD200X5 10
11 GBT16674.1-M10X30-8.8-A3L BOLT 1
13 9G662-68D000001A0 FIXED PLATE 1
14 GBT16674.1-M10X20-8.8-A3L BOLT 1
15 9F653-68D000003A0 CLAMP 4
16 9D652-65A000002A0 SUPPOT BRACKET 1
17 9F664-68A200000A0 AIR CONDITION ASSEMBLY 1
17.1 9F850-68A080000A0 COMPRESSOR 1
17.1 9F850-68A080000A0 COMPRESSOR 1
17.2 9F853-68A010003A0 AIR CONDITIONER BELT 1
17.3 9F664-68A200700A0 HOSE FROM COMPRESSOR TO CONDENSER 1
17.4 9G662-68A200600A0 HOSE FROM EVAPORATOR TO COMPRESSOR 1
17.5 9G662-68A200900B0 PIPE FROM LIQUID TANK TO EVAPORATOR 1
17.6 9G662-68A200300A0 CONDENSER ASSEMBLY 1
17.6.1 9G662-68A200301A0 CONDENSER COVER 1
17.6.2 9F850-68A070000A0 LIQUID TANK 1
17.6.2 9F850-68A070000A0 LIQUID TANK 1
17.6.3 9G662-68A200302A0 CONDENSER TO RESERVOIR HARD TUBE 1
17.6.4 9F657-68A100100A0 CONDENSER 1
17.6.5 9G662-68A200303A0 AIR BLOWER 1
17.6.6 9F657-68A100002A0 SHOCK ABSORBER 4
17.6.7 9F653-68C200301A0 SLEEVE 4
17.7 9G662-68A200100C0 EVAPORATOR 1
17.7.1 9G662-68A200101C0 TANK GROUP 1
17.7.2 9G662-68A200102C0 ELEMENT BLOCK 1
17.7.3 9G662-68A200103C0 ELEMENT BLOCK 1
17.7.4 9F653-68A020109C0 AIR BLOWER 1
17.7.5 9F653-68A020111B0 EXPANSION VALVE 1
17.7.6 9F653-68A020112B0 TEMPERATURE CONTROL UNIT 1
17.7.7 9F653-68A020115B0 RELAY 1
17.7.8 9G662-68A200104C0 WIRING HARNESS 1
17.8 9F850-68A090000A0 CONTROL PANEL OF AIR CONDITIONER 1
18 GBT16674.1-M8X35-8.8-A2L HEXAGON FLANGE BOLT 4
19 GBT96.1-8-A3L WASHER 4
2 9F850-68A000005A0 HOOP Φ19-25 4
20 9G662-68A000009A0 ARI CONDITIONER HARNESS 1
21 9G662-66E000001A0 GROMMET 1
22 9F653-64J000011A0 WIRE CLIP 1
23 9G661-68C210000A0 PLATE COMBINATION 1
24 GBT16674.1-M12X25-8.8-A3L BOLT 4
25 GBT846-ST4.8X13 SCREW 4
26 9G661-68C220000A0 PLATE COMBINATION 1
27 9F653-68D000002A0 CLAMP 3
28 9F657-68A000004A0 WATER TUBE 1
29 9F653-64J000012A0 WIRE CLIP 2
3 9G662-68B010000B0 COMPRESSOR BRACKET 1
3.1 GBT5783-M10X40-8.8-A3L BOLT 4
3.1 9G662-68B010200B0 ADJUSTING SCREW 1
3.11 GBT16674.1-M12X100-8.8-A3L BOLT 1
3.12 GBT96.1-12-A3L WASHER 2
3.2 GBT6177.1-M14-8-A3L NUT 2
3.3 9F850-68A010001A0 ADJUSTING BLOCK 1
3.4 9G662-68B010002B0 SPLINT 2
3.5 GBT6177.1-M10-8-A3L NUT 5
3.5 GBT6177.1-M10-8-A3L NUT 5
3.6 GBT5782-M10X50-8.8-A3L BOLT 1
3.7 GBT6177.1-M12-8-A3L NUT 2
3.8 GBT16674.1-M12X70-8.8-A3L BOLT 1
3.9 9G662-68B010001B0 PAD BLOCK 1
30 9F562-67A000001A0 TUBE 1
4 9F653-68A000010A0 PIPE CLAMP 2
5 GBT16674.1-M8X20-8.8-A2L BOLT 15
6 GBT6177.1-M8-8-A2L NUT 2
7 9F850-68A110000A0 WATER INLET VALVE OF WARM AIR CONDITIONER 1
8 9F853-68A000001A0 TRANSITION JOINT 1
9 9G662-68B000001A0 AIR CONDITION PIPE FIXED SUPPORT 1
