Description

LG853.12.05 30812000118 RUBBER PAD LONKING CDM853 Loader

1 GB T5783 Bolt M10x20
2 LG856.01Ⅰ.04 Water tank assembly LG856.01Ⅰ.04
3 GB T5783 Bolt M10x20
4 JB T8870-1999 Hose clamp φ44-64
5 LG856.01-002 Upper water pipe
6 LG853.01.01 Radiator water pipe joint
7 LG853.01.03 Diesel engine WD615G.220
8 LG856.01.05 Air pre-filter KA50
9 LG856.01.05-001 T shaped hoop
10 612600110116 Muffler assembly
11 61567G3-9000003 Fuel tank oil return pipe
12 GB T97.1 Washer 10
13 LG853.01.05 Flameout control assembly
14 LG853.01.06 Accelerator control assembly
15 GB T15329.1-2003 Torque converter oil return hose
16 JB T8870-1999 Hose clamp φ44-64
17 LG853.01.02 Converter oil return joint
18 612600080024 Fuel inlet pipe
19 LG853.01-002 Pressure connector 403727
20 GB T5782 Bolt M14x65
21 GB T97.1 Washer 10
22 GB T93 Washer 10
23 GB T93 Washer 10
24 GB T6170 Nut M14
25 GB T5782 Bolt M14x65
26 GB T97.1 Washer 10
27 GB T93 Washer 10
28 LG856.01Ⅰ-002 Water tank push rod
29 612600160003 Water pipe from pump to cooler
30 JB T8870-1999 Hose clamp φ44-64
31 LG853.01-007 Water tank rubber pad
32 LG856.01Ⅰ.01 Oil cooler S×48Z-00-00
33 LG856.01Ⅰ-001 Water tank water exit rubber pipe
34 JB T8870-1999 Hose clamp φ44-64
35 GB T93 Washer 10
36 GB T97.1 Washer 10
37 GB T5783 Bolt M10x20

Serial No Part Number Part Name Part Model
1 GB/T5783 Bolt M16
2 GB/T97.1 Washer 16
3 GB/T93 Washer 16
4 LG856.13.08.01 Fuel tank assembly
5 GB/T5783 Bolt M8
6 GB/T97.1 Washer 8
7 GB/T93 Washer 8
8 LG853.13.08.04 Air cleaner
9 LG853.13.08.02 Oil suction filter assembly
10 GB3452.1-1992 O-ring 45
11 LG853.13.08-003 Magnet φ80×φ40×12
12 LG853.13.08-002 Gasket
13 LG853.13.08.03 Oil drain cover
14 GB/T5783 Bolt M10 LG50E.07600A
15 GB/T97.1 Washer 10
16 GB/T93 Washer 10
17 LG853.13.08-001 Plug
18 LG853.13.08.01-009 Oil indicator bracket

Serial No Part Number Part Name Part Model
1 LG856.13.09.01 Oil tank body
2 LG853.13.08.05 Dip stick
3 LG853.13.08.04 Air cleaner
4 GB/T5783 Bolt M8
5 GB/T97.1 Washer 8
6 GB/T93 Washer 8
7 GB/T5783 Bolt M16
8 GB/T97.1 Washer 16
9 GB/T93 Washer 16
10 LG855.13.09.05 Oil return flange cover
11 GB/T5783 Bolt M10 LG50E.07600A
12 GB/T97.1 Washer 10
13 GB/T93 Washer 10
14 LG855.13.09.04 Oil return filter
15 LG856.13.09.002 Oil suction port
16 LG855.13.09-001 Spacer
17 LG853.13.08.03 Oil drain cover
18 LG853.13.08-002 Gasket
19 LG853.13.08-001 Plug
20 LG853.13.08-003 Magnetφ80χφ40×12
21 LG855.13.09.06 Oil suction filter
22 GB/T5783 Bolt M8
23 LG853.13.09.03 Flange disc
24 LG853.13.09-002 Spacer

Serial No Part Number Part Name Part Model
1 GB/T5783 Bolt M8
2 LG853.15.09 Electric horn assembly
3 GB/T93 Washer 8
4 LG855.15.01 Front frame wiring harness
5 LG856.15.15 Stopper wiring harness
6 LG856.15.11 Front combination lamp HD200×100
7 LG856.15.22 Wiper assembly 2D2531
8 LG856.15.17 Instruments assembly
9 LG856.15.18 MP3 player
10 LG856.15.12 Combination switch
11 LG856.15.23 Front work light
12 LG856.15.24 Front turn light
13 LG853.15.14 Electric lock switch JK324C
14 LG853.15.42 Combined switch JK321D
15 LG856.15.25 Ceiling light
16 LG856.15.21 Cab wiring harness
17 LG856.15.16 Central electric appliance control box
18 LG856.15.14 Central electric appliance control box wiring harness
19 LG856.15.19 Air conditioner assembly GK15.5.0C
20 LG853.15.05 Battery harness
21 LG856.15.08 Generator wiring harness
22 LG856.15.26 Engine water temperature sensor
23 LG853.15.27 Low pressure alarm switch SH361
24 LG853.15.26 Battery 6-QW-120
25 GB/T5783 Bolt M8
26 GB/T97.1 Washer 8
27 GB/T6170 Nut M8
28 LG856.15.27 Rear work light
29 LG856.15.04 Hood light wiring harness
30 LG856.15.28 Tail light
31 LG856.15.20 Reverse alarm DJ221B
32 LG853.15-001 Nylon strap ZD250×5
33 LG853.15.28 Main power switch DK2312
34 LG856.15.13 Rear frame wiring harness
35 LG853.01-005 Wiring clip LG50D.15008B
36 LG856.15.29 Engine oil pressure sensor
37 LG856.15.30 Transmission oil temperature sensor
38 LG856.15.31 Transmission oil pressure sensor
39 LG856.15.32 Fuel level sensor
40 LG855.15.44 Pressure type signal sender CY-II
41 LG856.15.33 Brake pressure sensor
42 LG853.15.30 Brake lamp switch JK150 60405020061
43 LG856.15.10 Instruments wiring harness

Serial No Part Number Part Name Part Model
1 LG856.02.01 Torque Converter Assy
2 LG853.02-001 Stud bolt
3 GB/T6171 Nut M10x1
4 GB/T93 Washer 10
5 LG856.02Ⅰ.02 Double transmission oil line assembly
6 GB/T93 Washer 10
7 GB/T5782 Bolt for cover plate
8 LG50EX.02-001 Oil suction rubber pipe

Serial No Part Number Part Name Part Model
1 LG853.02.01-001 402000-1
2 LG853.02.01-005 Pipe joint 402111A
3 LG853.02.01-007 Spring I 402229
4 LG853.02.01-008 Imported valve core 402233
5 LG853.02.01-006 Valve cove 402228A
6 LG853.02.01-011 Plug screw Z3/4〞 402223
7 GB/T5781 Bolt M8x20
8 GB/T93 Washer 10
9 GB/T5781 Bolt M8X20
10 LG853.02.01-015 Export valve core 402234
11 LG853.02.01-010 Spring II 402231A
12 LG853.02.01-012 Gasket 402215
13 LG853.02.01-009 Cover plate 402230A
14 LG853.02.01-014 Oil return joint 402204
15 LG853.02.01-013 Observation cover 402214A
16 LG853.02.01-002 Converter housing 402216
17 JB/T8547-97 Metal seal ring YHx125
18 GB/T5782 Bolt of the cover plate
19 GB/T93 Washer 10
20 LG853.02.01-003 Guide wheel seat 402222
21 LG853.02.01-004 Copper washer 402106

Serial No Part Number Part Name Part Model
1 LG853.02.02-001 Hinged bolt 402002A
2 LG855.02.02-001 Adapter 306016D
3 180H-270°-90H-25/28-Ⅰ-L1080 Rubber pipe from converter to filter
4 90H-H/25/28-IIBZ-25/18BG-L750 Rubber pipe from filter to converter
5 90H-45Q/25/28-Ⅰ-L2500 Rubber pipe from cooler to converter
6 90H-330°-90Q/25/28-Ⅰ-L2300 Rubber pipe from converter to cooler
7 JB1002-77 Washer 27
8 LG853.02.02-002 Adapter 402014B
9 JB1002-77 Washer 27
10 GB/T5783 Bolt M10
11 GB/T6170 Bolt for cover plate
12 GB/T93 Washer 10
13 GB/T97.1 Washer 10
14 LG855.02.02.01 Double transmission oil filter YFL-A400X25LS-G

Serial No Part Number Part Name Part Model
1 GB/T93 Washer 10
2 GB/T6170 Bolt for cover plate
3 LG853.03-001 Curved washers
4 LG853.03-002 Rubber pad
5 GB/T5782 Bolt for cover plate
6 LG856.03.01 Transmission assembly
7 GB5783 Bolt M10
8 GB/T97.1 Washer 10
9 GB/T93 Washer 10

Serial No Part Number Part Name Part Model
1 LG853.03.01.01 1st shaft assembly 403100
2 LG853.03.01-001 Middle cover seal gasket 403001A
3 LG853.03.01-002 End plate 403002B
4 LG853.03.01-003 Middle plate 403002A
5 LG50EX.03.01.02 3rd shaft assembly 403500
6 LG853.03.01-004 Screw plug 403062
7 GB1235-76 O-ring
8 GB/T5782 Bolt for cover plate
9 GB/T5782 Bolt for cover plate
10 GB/T5782 Bolt for cover plate
11 LG853.03.01-005 Housing 403005A
12 LG853.03.01.02 2nd shaft assembly 403200
13 LG853.03.01-006 1st gear oil cylinder body 403004A
14 LG853.03.01.06 1st gear piston assembly 403006A-010A
15 GB/T5782 Bolt for cover plate
16 LG853.03.01.07 Reverse 1st gear drive plate assembly 403012-013
17 LG853.03.01-007 Reverse 1st gear driven plate 403011
18 GB/T893.1 Retaining ring 90
19 LG853.03.01-008 Fixing plate 403023
20 LG853.03.01.08 Clutch Anchor assembly 403014-015
21 LG853.03.01-009 Cylindrical pin 403022
22 LG853.03.01-010 Spring pin shaft 403016
23 LG50EX.03.01.01 4th shaft assembly 403300
24 LG853.03.01-011 Spring 403017
25 LG853.03.01.09 Reverse piston assembly 403018A-020A
26 LG853.03.01-012 Seal gasket 403021
27 LG853.03.01.10 Transmission pump assembly 403600
28 LG853.03.01-013 Steering pump drive gear 403056
29 GB/T894.1 Retaining ring 90
30 LG853.03.01-014 Steering oil pump drive shaft 403055D
31 GB/T1096 Key 14×36
32 GB/T276 Ball bearing 6210N 55×100×21
33 LG853.03.01-015 Bearing bushing 403057
34 GB/T5782 Bolt for cover plate
35 GB/T276 Ball bearing 6210N 55×100×21
36 LG853.03.01-016 Seal gasket 403058
37 GB/T93 Washer 10
38 GB/T6170 Bolt for cover plate
39 GB/T898 Stud bolt
40 LG855.03.01-002 Brake pad LG50F.09004A
41 GB/T5786 Bolt M16x1.5×45
42 GB/T93 Washer 10
43 GB/T97.1 Washer 10
44 LG855.03.01.03 Caliper disk brake TC5Z(A)
45 GB/T93 Washer 10
46 LG853.03.01.04 Oil pan assembly 403400
47 LG855.03.01-001 Caliper fixing plate 403000-1
48 GB/T5782 Bolt for cover plate
49 GB/T93 Washer 10

Serial No Part Number Part Name Part Model
1 GB/T5782 Bolt 18
2 LG853.03.01-018 gasket 403029
3 GB1235-76 O-ring φ45×3.5
4 GB/T93 Washer 18
5 LG853.02.01-011 Plug 402223
6 GB/T5782 Bolt M10
7 LG853.03.01.13 Transmission control valve assembly 403700
8 13050-010 Oil drain cover plug Z1/4
9 LG855.03.01.02 Oil filling pipe assembly 403059-064D
10 LG853.03.01-019 Pressure plate 407021A
11 LG853.02.01-004 Copper washer 402106
12 LG853.02.01-005 Pipe joint 402111A
13 LG853.03.01.11 Connector assembly 403032-034
14 GB/T825 Ringbolt M18
15 GB/T119 Pin 10s7x10
16 LG853.03.01.12 Vent trap ZL30E.5.20
17 LG853.03.01-017 cylindrical plug 403028

Serial No Part Number Part Name Part Model
1 LG853.03.01.01-001 Rotary oil seal 403101
2 GB/T276 Ball bearing 6016 80
3 LG853.03.01.01-003 Imput 2nd gear 403103
4 LG853.03.01.01-002 Rotary oil seal 403102
5 GB301 Thrust ball bearing 55×78×16
6 LG853.03.01.01-004 Imput 1st gear 403104
7 GB/T276 Ball bearing 6311 55
8 LG853.03.01.01-005 Adjust shim 403105

Serial No Part Number Part Name Part Model
1 LG853.03.01.02.01 Overrunning clutch 403204-209B
2 LG853.03.01.02-006 Gasket 14 403217
3 LG853.03.01.02-007 Planetary gear 403218
4 GB309-84 Roller needle φ4×34.8
5 LG853.03.01.02-008 Spacer 403219
6 LG853.03.01.02-009 Retainer Ring 403220
7 LG853.03.01.02-010 Reverse planetary shaft 403221
8 LG853.03.01.02-011 1st gear inner gear ring 403222A
9 LG853.03.01.02-012 1st gear planetary carrier 403223
10 LG853.03.01.02-013 Stop disk 403224
11 GB/T93 Washer 10
12 LG853.03.01.02-001 Adjust shim 403202
13 GB/T5782 Bolt M10
14 LG853.03.01.02-016 1st gear planetary shaft 403227
15 LG853.03.01.02-014 Direct gear joint plate 403225
16 LG853.03.01.02-015 Sun gear 403226
17 GB894.1 Retaining ring 90
18 GB/T276 Ball bearing 6210N 55×100×21
19 LG853.03.01.02-002 Adjust shim 403212
20 GB/T276 Ball bearing 6110
21 LG853.03.01.02-003 Reverse planetary carrier 403213A
22 LG853.03.01.02-004 Stop gasket 403215
23 GB/T93 Washer 8
24 GB/T5780 Bolt M8x14
25 LG853.03.01.02-005 Reverse inner ring gear 403216

Serial No Part Number Part Name Part Model
1 LG853.03.01.05-001 Direct gear Compression plate 403501
2 LG853.03.01.05-004 Direct gear driven plate 403507
3 LG853.03.01.05.02 Direct gear piston assembly 403508A-510A
4 LG50EX.03.01.02-001 Middle shaft output gear 403511J
5 LG853.03.01.05-006 Direct gear oil cylinder body 403512A
6 LG853.03.01.05-007 Disk shape spring 403513
7 GB/T894.1 Spacer 65
8 GB/T283 Cylindrical roller bearing 20×47×14
9 LG853.03.01.01-001 Rotary oil seal 403101
10 GB/T276 Ball bearing 6411 55
11 LG853.03.01.01-002 Rotary oil seal 403102
12 GB/T276 Ball bearing 6022 110
13 LG853.03.01.05-008 Adjust shim 403517
14 LG853.03.01.05-009 Stop gasket 403518B
15 LG853.03.01.05-010 Pin 403516
16 GB/T119 Pin φ10S7×30
17 LG853.03.01.05-002 Direct gear shaft 403502A
18 GB/T5785 Bolt M12x1.25×100
19 LG853.03.01.05-003 Cylindrical pin 403504
20 GB/T5782 Bolt M8
21 GB/T6170 Nut M8
22 GB/T93 Washer 8
23 LG853.03.01.05.01 Direct gear drive plate 403505-506

Serial No Part Number Part Name Part Model
1 LG853.03.01.03-001 Rear output flange 403301D
10 LG853.03.01.03-005 Output shaft 403314
11 GB/T283 Column roller bearing NUP312E
12 LG853.03.01.03-006 Spacer 403305
13 LG853.03.01.03-007 Oil seal 403304C
14 HG4-692-67 Oil seal 120
15 LG853.03.01.03-008 Gasket 403317
16 GB1235-76 O-ring 52
17 LG855.03.01.01-001 Front output flange 403316B
2 GB890-80 Retaining nut M33X1.5
3 LG853.03.01.03-002 Gasket 403303
4 LG853.03.01.03-003 Oil seal seat 403304B
5 GB1235-76 O-ring 130
6 HG4-692-67 Oil seal SG70X95X12
7 GB/T893.1 Spacer 130
8 GB/T276 Ball bearing 6312
9 LG50EX.03.01.01-001 Output shaft gear 403311J

Serial No Part Number Part Name Part Model
1 LG50EX.04.01 Front drive axle assembly
2 GB/T5786 Bolt M12
3 GB/T889.1 Nut M12X1.5
4 LG853.04-001 Locating ring LG50F.04001A
5 LG856.04.02 Front drive shaft assembly LG50F.04201A
6 GB/T5783 Bolt M16
7 GB/T97.1 Washer 16
8 GB/T93 Washer 16
9 LG855.04.03 21kg LG50F.04203A
10 GB/T5786 Bolt M12
11 GB/T93 Washer 12
12 LG50EX.04.05 Rear drive axle assembly LG50F.04000
13 LG853.04.05 Rim assembly
14 GB/T2980 Tire 23.5-25 E-3
15 GB/T5784 Bolt M30X2X145-10.9
16 GB/T889.1 Nut M30
17 GB/T5784 Bolt M30

Serial No Part Number Part Name Part Model
1 ZL50EX.04.01.01 Wheel reductor assembly LG50F.04400A
2 ZL50EX.04.01.02 Front and rear axle housing assembly LG50F.04500A
3 ZL50EX.04.01.03 Main reducer assembly LG50F.04300A
4 LG853.04.01.04 Vent pipe 404002
5 GB6173-86 Bolt M16x1-6
6 ZL50EX.04.01-001 Semi shaft LG50F.04002A
7 LG853.04.01.03 Caliper disk brake 408100
8 ZL50EX.04.01-002 Rim nut LG50F.04003A
9 LG853.04.01-023 Screw plug
10 GB93-87 Gasket 14
11 GB5785-86 Bolt M14
12 GB5785-86 Bolt M14
13 GB5786-86 Bolt M14
14 GB/T119-1986 Pin A12x20
15 LG853.04.01-020 Bolt M20x1.5×56 408120
16 GB93-87 Washer 20
17 LG853.04.01.03.02 Brake pad 408107-108
18 GB93-87 Washer 10
19 LG853.04.01.03-011 408114

Serial No Part Number Part Name Part Model
1 ZL50EX.04.01.01 Wheel reductor assembly LG50F.04400A
2 ZL50EX.04.01.02 Front and rear axle housing assembly LG50F.04500A
3 ZL50EX.04.05.01 Main reducer assembly LG50F.04300A
4 LG853.04.01.04 Vent pipe 404002
5 GB6173-86 Bolt M10x1-6
6 ZL50EX.04.01-001 semi shaft LG50F.04002A
7 LG853.04.01.03 Caliper disc brake assembly 408100
8 ZL50EX.04.01-002 Rim nut LG50F.04003A
9 LG853.04.01-023 Screw plug
10 GB93-87 Gasket 14
11 GB5785-86 Bolt M14
12 GB5785-86 Bolt M14
13 GB5786-86 Bolt M14
14 GB/T119-1986 Pin A12
15 LG853.04.01-020 Bolt M20 408120
16 GB93-87 Washer 20
17 LG853.04.01.03.02 Brake pad 408107-108
18 GB93-87 Washer 10
19 LG853.04.01.03-011 Bolt pin 408114

Serial No Part Number Part Name Part Model
1 LG855.05.01 Transmission control assembly LG50E.05000
2 LG855.05.02 Working control assembly LG50E.07600A

Serial No Part Number Part Name Part Model
1 LG855.05.01.01 Transmission control cable 1.95kg
2 GB/T5783 Bolt M10 LG50E.07600A
3 GB/T93 Washer 10
4 GB/T97.1 Washer 10
5 LG853.05.01-002 Transmission cable retaining plate
6 LG853.05.01-001 Fastening block
7 GB/T5783 Bolt M8
8 GB/T93 Washer 8
9 LG853.05.01-002 Speed control flexible shaft securing block
10 GB/T5782 Bolt M6
11 GB/T93 Washer 6

Serial No Part Number Part Name Part Model
1 LG853.05.02-001 Knuckle connector
2 LG853.05.02-002 Securing plate
3 LG855.05.02.01 Cable shaft LG50E.07602A
4 GB/T5783 Bolt M10
5 GB/T6170 Nut M10
6 GB 882 Pin shaft
7 GB/T97.1 Washer 8
8 GB/T91 Cotter pin 3.2
9 LG853.05.02-003 Knuckle connector
10 GB/T97.1 Washer 10
11 LG853.05.02.02 Securing bracket
12 LG853.05.02-004 Cardinal axis seat
13 LG853.05.02-005 Cardinal axis sleeve
14 GB/T5783 Bolt M10
15 GB/T96 Washer 10
16 GB/T93 Washer 8
17 LG853.05.02-006 Setting screw
18 LG853.05.02-007 Shaft holder
19 LG853.05.02-008 Spacer
20 GB/T93 Washer 10
21 GB/T5783 Bolt M10
22 LG853.05.02-009 Bush
23 LG853.05.02-010 Shaft
24 LG855.05.02.02 Gear shift assy LG50E.07601-601A
25 LG853.05.02-011 Knob M12

Serial No Part Number Part Name Part Model
1 DW-3-2/2 Joystick
2 LG856.05-001 Joystick signal wire
3 Ocean-C1-50Z Controller
4 LG856.05-002 Power cord
5 LG856.05-003 Solenoid wire

Serial No Part Number Part Name Part Model

1 L570 GB/T5783 Bolt M10
2 GB1235-76 O-ring 38
3 90H-F(32)/25/28-2S- Priority valve oil inlet hose
4 GB1235-76 O-ring 45
5 LG853.07-007 Press plate
6 GB/T5783 Bolt M10
7 P5100-F80NL457.97G Steering pump
8 LG853.06-001 Seal gasket
9 H-H/19/18-I-L3600 Hose from steering gear to cooler
10 H-H/19/18-I-L2300 Cooler oil return hose
11 LG855.02.02-001 Adapter 306016D
12 GB/T93 Washer 10
13 JB1002-77 Washer 27
14 GB/T93 Washer 12
15 GB/T97.1 Washer 12
16 GB/T6170 Nut M12
17 GB/T3452.1-1992 O-ring 46.2
18 GB/T5783 Bolt M12
19 LG855.06.01 Steering pump oil inlet pipe 506002-003C
20 LG855.06.02 Steering pump oil outlet pipe 506004-004C
21 φ51×4-L520 Oil suction hose
22 JB/T8870-1999 Hoop (φ55—71)
23 GB/T97.1 Washer 10
24 LG855.06.04 Rear frame turning transition pipe 506005-006C(long)
25 LG855.06.05 Rear frame turning transition pipe 506005-006C(short)
26 LG853.06-005 Rear frame turning transition connector press plate 506007C
27 H-H/19/18-II-L1252 Steering gear port A,B oil outlet hose
28 H-H/19/18-II-L1152 Steering cylinder oil inlet hose
29 90H-H-8/8-Ⅱ-L800 (M14×1.5) Steering sensing/priority valve leakage hose
30 LG855.06.06 Right steering cylinder small chamber pipe LG50F.06004-004A
31 JB999-77 Articulating bolt for pipe connector M22
32 JB1002-77 Washer 22
33 LG856.06.15 Left steering cylinder
34 LG856.06I.02 Hydraulic steering gear
35 H-H/19/18-II-L685 Hose between steering cylinder
36 LG855.06.07 Right steering cylinder big chamber pipe LG50F.06001-003A
37 LG855.06.08 Left steering cylinder big chamber pipe LG50F.06005-005A
38 GB/T3452.1-1992 O-ring 50
39 GB/T3452.1-1992 O-ring 65
40 LG855.06-001 Steering cylinder connecting bracket LG50F.06301A
41 LG855.06.09 Front frame turning right transition pipe LG50F.06007-007A
42 LG855.06.10 Front frame turning left transition pipe LG50F.06008-008A
43 GB3733.2-83 Insert type straight connector G8(M14
44 JB1002-77 Washer 12
45 LG853.06-003 Steering gear adapter 506001C
46 LG855.06.11 Left steering cylinder small chamber pipe LG50F.06006-006A
47 90H-H/19/18-II-L550 Hose from priority valve to steering gear
48 LG853.06-006 Priority valve oil outlet adapter 506009C
49 JB1002-77 Washer 33
50 GB/T5782 Bolt M10
51 LG853.06.10 Priority valve YXL-F250F-N7
52 LG856.06.16 Right steering cylinder
53 JB1002-77 Washer 20
54 LG853.06-004 Press plate
55 GB/T5783 Bolt M10
56 90F-F/25/28-2S-L940 Priority valve distributing hose

Serial No Part Number Part Name Part Model
1 GB/T6170 Nut M10
2 GB/T93 Washer 10
3 GB/T97.1 Washer 10
4 LG855.06.02.01 Steering wheel assembly
5 LG853.06.02.02 Conduction bush 306114-115D
6 GB/T5783 Bolt M6
7 GB/T93 Washer 6
8 LG853.06.02-001 Electric lock securing board 306113D
9 LG853.06.02.03 Combined switch board 306110-111D
10 GB276-89 Single-row radial ball bearing 104
11 GB/T5783 Bolt M6
12 LG853.06.02.04 Steering shaft
13 LG853.06.02.05 External sleeve
14 GB/T5782 Bolt M10
15 GB/T301-1995 Roller bearing 51106
16 LG853.06.02.08 Securing seat
17 LG853.06.02.07 Redirector (valve) TLF-E1000C（FKBR3020）
18 LG853.06.02-003 Adjusting shim
19 GB/T6170 Nut M6

Serial No Part Number Part Name Part Model
1 GB/T5783 Bolt M10
2 GB/T93 Washer 10
3 GB/T97.1 Washer 10
4 LG855.07-009 Tilt cylinder fender apron
5 LG853.07-005 Tilt cylinder connecting bracket
6 GB/T3452.1-1992 O-ring 95
7 GB/T3452.1-1992 O-ring 80
8 LG855.07.01 Tilt cylinder LG50F.07100A
9 GB/T5782 Bolt M10
10 GB1235-76 O-ring 38
11 LG855.07.03 Tilt cylinder front chamber pipe
12 30F(32)-H/25/28-2S-L1500 Hose from distribution valve to tilt cylinder
13 LG855.07.04 Tilt cylinder rear chamber pipe LG50F.07003-003A
14 LG855.07II.05 Lift cylinder front chamber pipe
15 LG855.07II.06 Lift cylinder front chamber pipe
16 LG855.07I.07 Lift cylinder rear chamber pipe
17 LG855.07I.08 Lift cylinder rear chamber pipe LG855.07I.07?
18 LG853.07-006 Lift cylinder connecting bracket
19 GB/T3452.1-1992 O-ring 71
20 80H-H/25/28-2S-L1500 Lift cylinder hose
21 H-H/38/42-I-L435 Distribution valve oil return hose
22 LG855.07-001 Pipe clip
23 GB/T5783 Bolt M8
24 GB/T97.1 Washer 8
25 GB/T93 Washer 8
26 GB/T6170 Nut M8
27 LG853.07-004 Rear frame oil return transition connector press plate LG50F.07031A
28 GB/T5782 Bolt M10
29 LG855.07.09 Front frame oil return transition connector LG50F.07032-033A
30 H-H/38/42-II-L1152 Articulated oil return hose
31 H-H/32/34-4S-L1260 Articulated oil inlet hose
32 LG853.07-002 Front (rear) frame oil inlet transition connector press plate LG50F.07035A
33 GB/T5782 Bolt M10
34 P5100-F100NM457 97/P124-G10Y03G Implement and pilot duplex pump
35 LG853.06-001 Seal gasket
36 GB/T97.1 Washer 12
37 GB/T6170 Nut M12
38 GB/T93 Washer 12
39 φ51×4-L520 Oil suction hose
40 JB/T8870-1999 Hoopφ51-70
41 LG853.07-007 Press plate
42 GB1235-76 O-ring 45
43 45F(32)-270 Implement pump oil outlet hose
44 LG855.07.10 Implement pump oil outlet pipe LG50F.07017-018A
45 H-H/38/42-I-L575 Oil return hose
46 LG855.07.11 Rear frame oil return transition connector LG50F.07034-034A
47 LG50EX.07.05 Front frame oil inlet transition connector LG50F.07036-036B
48 GB/T5782 Bolt M12
49 LG50EX.07.06 Pipe from distribution valve to lift arm rear chamber Ⅰ LG50F.07010-011A
50 LG50EX.07.07 Pipe from distribution valve to lift arm front chamber Ⅰ LG50F.07006-008A
51 LG50EX.07-001 Press plate LG50F.07016A
52 GB/T5783 Bolt M12
53 GB1235-76 O-ring 50
54 GB/T5782 Bolt M10
55 GB/T6170 Nut M10
56 LG50EX.07-005 Pipe clip
57 LG50EX.07.13 Lift arm pipe fixing board
58 LG50EX.07.08 Pipe from distribution valve to lift arm rear chamber Ⅱ LG50F.07012-012A
59 LG50EX.07.09 Pipe from distribution valve to lift arm front chamber Ⅱ LG50F.07009-009A
60 LG855.07-003 Pipe clip
61 GB/T5783 Bolt M8
62 GB/T5783 Bolt M10
63 LG855.07II.02 Lift cylinder
64 LG50EX.07.14 Lift arm pipe fixing board
65 LG50EX.07.10 Distribution valve oil return hose LG50F.07015-015B
66 LG856.07.11 Pilot control system
67 90F(38)-H/32/34-4S-L800 Distribution valve oil inlet hose
68 GB/T3452.1-1992 O-ring 58
69 LG856.07I.03 Hydraulic system oil return pipe LG50F.07019-020A
70 LG853.07-001 Press plate LG50F.07037A
71 LG856.07I.04 Implement pump oil inlet pipe LG50EX.07.01
72 GB/T3452.1-1992 O-ring 58
73 GB/T5782 Bolt M12
74 GB/T5782 Bolt M8
75 LG50EX.07-003 Pipe clip LG50F.07025A
76 LG50EX.07-004 Pipe clip LG50F.07026A
77 LG855.07-006 Pipe clip press plate
78 LG50EX.07.16 Hose from distribution valve to tilt cylinder fixing bracket
79 GB/T5783 Bolt M10
80 GB/T5783 Bolt M12

Serial No Part Number Part Name Part Model
1 LG50EX.09.02 Parking brake air chamber QZ50-3507001
2 LG50EX.09.04 Parking brake air chamber fixing bracket LG50F.09007-008A
3 GB5783 Bolt M16
4 GB/T97.1 Washer 10
5 GB/T 93 Washer 10
6 90C-C/8I-L=1800 Hose from manual control brake valve to parking brake air chamber
7 LG856.09.02 Manual control brake valve QZ50
8 90C-C/8I-L=1400 Hose from manual control brake valve to cutoff cylinder
9 LG856.08-001 Four-circuit protecting valve outlet connector
10 JB1002 Washer 16
11 LG853.08-013 Connector
12 JB1002 Washer 22
13 LG856.09.01 Parking brake air tank assembly
14 C/8I-L=3400 Hose from protecting valve to parking brake air tank
15 C/8I-L=3200 Hose from parking brake air tank to manual control valve
16 LG50EX.09.03 XZ cutoff cylinder
17 LG50EX.09-001 Hand control brake valve air outlet connector LG50F.09002A
18 LG50EX.09-003 Cutoff cylinder air inlet connector LG50F.09003A
19 LG50EX.09-002 Manual control brake valve air inlet connector LG50F.09001A
20 LG856.09-001 Brake air chamber inlet connector

Serial No Part Number Part Name Part Model
1 LG853.08.04 Oil inlet pipe
2 LG853.08.03 Front booster pump oil outlet pipe
3 LG853.08-004 Connecting bolt
4 LG853.08-005 Washer
5 LG856.08.02 Booster pump LG-ZL50C
6 90C-C/8I-L=2300 Hose from brake valve to front booster pump
7 LG856.08.07 Double chamber air brake valve HP3514B
8 JB1002 Copper washer 22
9 LG853.08-007 Pressure connector seat
10 C/8I-L=3600 Hose from brake valve to right air tank
11 C/8I-L=3300 Hose from brake valve to left air tank
12 90C-C/8I-L=1400 Hose from brake valve to rear booster pump
13 LG853.08.06 Rear axle oil pipe 508003-003
14 LG853.08.11 Brake hose
15 GB/T 5783 Bolt M16
16 GB/T93 Washer 16
17 GB/T 97.1 Washer 16
18 LG853.08-015 Air compressor outlet pipe bracket 508009C-Ⅱ
19 LG853.08-003 Pipe clip φ12
20 GB/T 5783 Bolt M12
21 GB/T 93 Washer 12
22 GB/T 97.1 Washer 12
23 GB/T 6170 Nut M12
24 LG853.08.07 Compressor air outlet pipe
25 LG856.08.01 Air tank assembly
26 LG856.08.03 Recoil air tank HP-3511CB-18
27 LG853.08.12 Air pressure gauge pipe 1300
28 LG856.08-001 Four-circuit protecting valve outlet connector
29 LG856.08.04 Four-circuit protecting valve HP3518
30 GB/T 5783 Bolt M8
31 GB/T 93 Washer 8
32 GB/T 97.1 Washer 8
33 GB/T 5783 Bolt M10
34 GB/T 93 Washer 10
35 GB/T 97.1 Washer 10
36 LG853.01-005 Pipe clip
37 GB/T 5783 Bolt M6
38 GB/T 93 Washer 6
39 LG853.08.05 Front axle pipe
40 90C-C/8I-L=2400 Hose from protecting valve to right air tank
41 90C-C/8I-L=2700 Hose from protecting valve to left air tank
42 90C-90 Hose from dryer to protecting valve
43 LG856.08-003 Dryer articulating bolt
44 20791-18-05/20711-18-05XJS8XL1600 Hose from air compressor to dryer
45 LG856.08.05 Dryer HP3511
46 LG856.08.06 Dryer bracket
47 90C-C/8I-L=2000 From dryer to recoil air tank
48 LG856.08-004 Stopper
49 JB1002 Copper pad 16
50 LG856.08-005 Recoil air tank fixing board

Serial No Part Number Part Name Part Model
1 LG856.10Ⅱ.01 Front frame
2 GB/T5783 Bolt M10
3 GB/T93 Washer 10
4 LG855.10-001 Cover board LG855.10001A
5 LG855.10.04 Tilt cylinder rear pin weldment LG50F.10002-003A
6 JB/T7940.1-1995 Oil cup M10 GB/T1152
7 GB/T5783 Bolt M20
8 GB/T93 Washer 20
9 GB/T97.1 Washer 20
10 LG855.10.05 Lift arm upper pin weldment LG50F.10005-005A
11 LG855.10.06 Lift cylinder rear pin weldment LG50F.10007-008A
12 LG855.10.07 Rear steering pin weldment LG50F.10011-012A
13 LG855.10-002 Steering cylinder rear tray LG50F.10013A
14 GB/T5783 Bolt M16
15 GB/T93 Washer 16
16 LG855.10.08 Oil tank bracket LG50E.10001-002A
17 LG856.10Ⅰ.02 Rear frame
18 LG856.10.02 Rear frame
19 LG855.10-003 Oil filter bracket 510009C
20 LG855.10.03 Oscillating suspension LG50F.10300B
21 LG853.10-018 Block 410002B
22 LG855.10-004 Copper pad LG50F.10035A
23 LG855.10.09 Oscillating suspension pin LG50F.10033-034A
24 LG855.10.10 Oscillating suspension oil filling pipe 1 LG50F.10042-042A
25 GB/T5782 Bolt M12
26 GB/T93 Washer 12
27 GB/T6170 Nut M12
28 GB/T297-1994 Bearing 32215 GB297-84 7515E
29 LG853.10-008 End cover 510014C
30 LG853.10-007 Articulating pin 75X230
31 LG853.10-006 Press plate 510011C
32 GB/T13871-1992 FB-type seal 75
33 LG853.10-005 Upper bearing cover
34 LG853.10-004 Lower bearing cover
35 LG853.10-003 Adjusting spacer 510018C
36 LG853.10-001 Upper shaft sleeve 75X85X66
37 LG853.10-002 Lower shaft sleeve 106X75X52
38 GB/T13871-1992 FB-type seal 85
39 GB/T5783 Bolt M12
40 LG855.10.11 Front steering pin weldment LG50F.10015-016A
41 LG855.10.12 Right front steering pin oil filling pipe LG50F.10018-018A
42 LG855.10.13 Left front steering pin filling pipe
43 LG855.10-006 Adjusting washer
44 JB/T7940.2-1995 Oil cup M10 GB/T1153
45 GB/T5783 Bolt M16
46 LG855.10.14 Oscillating suspension oil filling pipe 2 LG50F.10041-041A
47 LG855.10-007 Oscillating suspension pin sleeve LG50F.10032A
48 LG853.01-005 Wiring clip LG50D.15008B
49 GB/T5783 Bolt M8
50 GB/T93 Washer 8
51 GB/T97.1 Washer 8
52 LG853.10-022 Lower end cover

Serial No Part Number Part Name Part Model
1 LG856.11.01 Bucket
2 LG853.11.02 Pull rod
3 LG855.11.03 Lift arm LG855.11300A
4 LG853.11.04 Tilt arm
5 LG853.11-001 Lift arm upper shaft sleeve 衬套（动臂缸）CDM855
6 JB/T7940.1-1995 Oil cup M10 GB/T1152
7 LG855.11.05 Lift cylinder upper pin weldment LG50F.11017-018
8 GB/T5783 Bolt M24
9 GB/T93 Washer 24
10 GB/T97.1 Washer 24
11 GB9877.1-88(B type) Oil seal 120
12 LG853.11-002 Tilt arm middle shaft sleeve 120X140X106
13 LG853.11.06 Tilt arm middle pin weldment
14 LG853.11-004 Pull rod sleeve 80X100X120
15 GB/T93 Washer 20
16 GB/T97.1 Washer 20
17 GB/T5783 Bolt M20
18 LG853.11-005 O-ring
19 LG855.11.06 Bucket lower pin weldment LG50F.11001-002
20 LG853.11-003 Lift arm lower shaft sleeve 70X90X120
21 LG853.11.07 Bucket upper pin weldment
22 LG856.11.01-002 Tooth sleeve
23 LG856.11.01-004 Pin
24 LG856.11.01-005 Sprag

Serial No Part Number Part Name Part Model
1 LG856.12.01 Cab assembly
2 LG856.12.02 Left door glass
3 LG856.12.03 Right door
4 LG856.12.02-001 Left door glass
5 LG856.12.03-001 Right door glass
6 LG856.12.05 Outer front light shade
7 LG856.12.09 Inner rearview mirror
8 LG853.12.08 Rearview mirror
9 LG856.12-001 Front windscreen
10 LG856.12.07 Instrument panel bracket
11 LG856.12-002 Left front glass
12 LG856.12-003 Right front glass
13 LG856.12.02.02 Door lock
14 LG856.12.06 Pilot control box
15 LG856.12.11 Seat
16 lG853.12.05 Rubber pad
17 LG853.12-010 Washer
18 LG853.12-012 Pad
19 LG855.12-001 Pin
20 GB/T889.2 Nylon self-lock nut M18
21 LG855.12-009 Washer
22 LG856.12.04 Shock absorber
23 GB/T5783 Nut M8
24 GB/T97.1 Washer 8
25 GB/T93 Washer 8
26 LG856.12.02.03 Latch lock
27 GB/T5783 Bolt M8
28 LG856.12-004 Left rear glass
29 LG856.12-005 Right rear glass
30 LG856.12-006 Rear glass

Serial No Part Number Part Name Part Model
1 LG856.13.01 Front left mudguard
2 LG856.13.02 Front rear mudguard
3 LG856.13.03 Combination light bracket
4 GB/T5783 Bolt M12
5 GB/T93 Washer 12
6 GB/T97.1 Washer 12
7 LG856.13.04.01 Left platform front rail
8 LG856.13.05.01 Right platform front rail
9 LG856.13.04 Left platform
10 LG856.13.05 Right platform
11 LG856.13.04-016 Left platform rear rail
12 LG856.13.05-016 Right platform rear rail
13 LG856.13.06.01 Front hood
14 LG856.13.06.02 Upper hood
15 LG856.13.06.12 Rail
16 LG856.13.06.05 Left door
17 LG856.13.06.06 Right door
18 LG856.13.06.07 Rear hood
19 LG856.13.06.08 Rear cover board
20 LG856.13.07 Counterweight
21 LG856.13.06.03 Left rear mudguard
22 LG856.13.06.04 Left rear mudguard
23 GB/T5783 Bolt M16
24 GB/T97.1 Washer 16
25 GB/T93 Washer 16
26 LG856.13.08.01 Fuel tank assembly
27 LG856.13.09 Engine oil tank assembly
28 GB/T5783 Bolt M12
29 GB/T97.1 Washer 12
30 GB/T93 Washer 12
31 LG856.13.08.01 Fuel tank assembly
32 LG856.13.09 Engine oil tank assembly
33 GB/T5783 Bolt M12
34 GB/T97.1 Washer 12
35 GB/T93 Washer 12
36 LG853.13.06.09 Hood lock
37 LG856.13.06-001 Pin

Serial No Part Number Part Name Part Model
1 LG853.15.09 Electric horn assembly
2 GB/T93 Washer 8
3 GB/T5783 Bolt M8
4 LG856.15Ⅰ.01 Front frame wiring harness
5 LG856.15.11 Front combination lamp HD200×100
6 LG856.15.22 Wiper assembly 2D2531 单轴的
7 LG856.15Ⅰ.17 Instruments assembly
8 LG856.15.18 MP3 player
9 LG856.15Ⅰ.34 Combination switch
10 LG856.15.23 Front work light
11 LG856.15.24 Front turn light
12 LG853.15.14 Electric lock switch JK324C
13 LG853.15.42 Combined switch JK321D
14 LG856.15.25 Ceiling light
15 LG856.15Ⅰ.02 Cab wiring harness
16 LG856.15Ⅰ.32 Central electric appliance control box
17 LG856.15.19 Air conditioner assembly GK15.5.0C
18 LG853.15.05 Battery harness
19 LG856.15Ⅰ.08 Generator wiring harness
20 LG856.15.26 Engine water temperature sensor
21 LG853.15.27 Low pressure alarm switch SH361
22 LG853.15.26 Battery 6-QW-120
23 GB/T5783 Bolt M8
24 GB/T97.1 Washer 8
25 GB/T6170 Nut M8
26 LG856.15.27 Rear work light
27 LG856.15Ⅰ.04 Hood light wiring harness
28 LG856.15.28 Tail light
29 LG856.15.20 Reverse alarm DJ221B
30 LG853.15-001 Nylon strap ZD250×5
31 LG853.15.28 Main power switch DK2312
32 LG856.15Ⅰ.03 Rear frame wiring harness
33 LG853.01-005 Wiring clip LG50D.15008B
34 LG856.15.29 Engine oil pressure sensor
35 LG855.15.43 Pressure difference message sender
36 LG856.15.30 Transmission oil temperature alarm switch
37 LG856.15.31 Transmission oil pressure alarm switch
38 LG856.15.32 Fuel level sensor
39 LG856.15.34 Centralized lubricating system assembly
40 LG856.15.33 Lower pressure alarm switch Ⅰ
41 LG853.15.30 Brake lamp switch JK150 60405020061
42 LG856.15Ⅰ.07 Instruments wiring harness
