Description

14400480 Hose Assembly SDLG E6205F E6210F E6225F Excavator Parts

1 钢管 PIPE 14400465
2 钢管 PIPE 14400467
3 O型圈 O-ring 11221995
4 弹垫 SPRING WASHER 11210064
5 内六角螺钉 HEX. SOCKET SCREW 11210152
6 管夹 CLAMP 14404331
7 管夹 CLAMP 14404332
8 垫圈 PLAIN WASHER 11210197
9 六角螺钉 HEXAGON SCREW 11210124
10 管夹 CLAMP 11211130
11 垫圈 PLAIN WASHER 11210201
12 螺栓 HEXAGON SCREW 11210191
13 胶管 HOSE ASSEMBLY 14400480
14 钢管 PIPE 14400469
15 钢管 PIPE 14400471

动臂油缸-80 Lifting cylinder assembly

1 缸筒24A030480 CYLINDER TUBE 11219405
2 活塞杆24A010190 PISTON ROD 11219406
3 活塞盖24A070110 Head 11210497
4 滑动轴套24S180401 BUSHING 11211803
5 挡圈24C007010 RETAINING RING 11211774
6 挡圈24C001140 RETAINING RING 11210181
7 缓冲套24C060010 RUBBER CUSHION 11210551
8 活塞24A080190 PISTON 11210431
9 垫圈24C008010 LOCK WASHER 11211639
-11224712 9216-06520 Y 1
10 锁紧螺母24C012020 LOCK NUT 11211342
11 紧固螺钉24T516605 SCREW 11214764
-4.12E+12 13949445 Y 12
12 紧固螺钉24T908121 SET SCREW 11213437
13 衬垫24A052240 PAD 11211340
14 防尘圈24D208002 SEALING RING 11211778
15 挡圈24E008026 RING 11211797
16 密封圈24F008021 SEALING 11211776
17 缓冲圈24H008005 SEALING 11211343
18 密封环24M31250B RING 11211780
19 O型圈24K01150A O-RING 11218610
20 密封环24M312502 RING 11211795
21 O 形圈24K00650A O-RING 11210177
22 主密封24P512501 SEALING 11210421
-11224668 14512071 Y 1
23 支撑环24G212507 WEAR RING 11211783
24 纳污环24N012504 SEALING RING 11211800
25 衬套24C054010 BUSHING 11219400
26 防尘圈24R308043 SEALING 11210870
27 油杯 LUBRICATING NIPPLE 11210001
-4030000676 914167— N 1
28 轴衬24C054020 BUSHING 11219401
29 密封件包24A000151S SEALING KIT 11210469
30 油缸24A000151 BOOM CYLINDER 11219000
