Description

0501 213 016 0501213016 Clutch Friction Disc ZF transmission

1 4642 306 152 阀体 Valve body
2 4620 306 248 锁片 Locking plate
3 0732 040 838 弹簧 Spring
4 4620 306 245 阀芯 Valve core
5 0732 040 837 弹簧 Spring
6 0730 061 778 隔套 Screw – in sleeve
7 0769 120 747 垫片 Shim
8 4620 306 247 衬套 Bushing
9 4642 306 094 阀芯 Valve core
10 0732 041 254 弹簧 Spring
11 4620 306 252 挡销 Backing pin
12 0634 303 118 O型圈 O-ring
13 4620 306 413 阀芯 Valve core
14 0732 041 390 挡销 Backing pin
15 4620 306 414 固定板 Fixed plate
16 4644 306 549 阀芯 Valve core
17 4644 306 241 固定板 Fixed plate
18 4620 306 255 阀芯 Valve core
19 0732 041 154 弹簧 Spring
20 0732 041 254 弹簧 Spring
21 4642 306 093 阀芯 Valve core
22 4620 306 252 挡销 Backing pin
23 0643 303 118 O型圈 O-ring
24 4642 306 049 锁片 Locking plate
25 4644 306 549 挡销 Backing pin
26 0732 041 254 弹簧 Spring
27 4642 306 095 阀芯 Valve core
28 0732 041 254 弹簧 Spring
29 4642 306 096 阀芯 Valve core
30 4620 306 252 挡销 Backing pin
31 0643 303 118 O型圈 O-ring
32 4620 306 415 盖 Cover
33 4620 306 479 纸垫 Gasket
34 GB/T5783-1987 六角头螺栓M8*18 Hex. Bolt
35 0510 315 338 电磁阀 Solenoid valve
36 GB/T70-1985 内六角头螺栓M5*12 Socket bolt
37 GB/T859-1987 弹簧垫圈5 Spring washer
38 4620 206 019 电缆组件 Cable set
39 GB/T65-1985 开槽螺钉M4*12 Slotted screw
40 GB/T860-1988 鞍型弹性垫圈 Saddle flexible washer
41 4620 306 259 电磁阀罩壳 Solenoid valve box
42 0634 303 951 O型圈 O-ring
43 4620 306 241 弓夹 Clamp
44 JB/T1000-1977 螺塞M10*1 Plug
45 Q20-03 紫铜垫圈 A10*13.5 Copper washer
1 6006 030 818 H 挡位选择器SG-3SN2/A Speed selector
2 6029 204 526 电缆(变速器) L=2.0m Cable
1 01582-11210 螺母M12*1.5 Nut
2 01583-51207 螺母M12*1.5 Nut
3 01643-51232 垫圈12 Washer
4 263-12-01000 万向传动轴 Shaft joint
5 GB/T32.3-1998 螺栓M12*1.5*25 Bolt
6 01090-51245 螺栓M12*1.5*45 Bolt
7 263-12-02000 万向传动轴 Shaft joint
8 01090-51055 螺栓M10*1.25*55 Bolt
9 01643-51032 垫圈10 Washer
10 01582-11008 螺母M10*1.25 Nut
11 01583-51006 螺母M10*1.25 Nut
